Julabo^® HighTech series refrigerated/heating circulator

CE compliant

FP45-HL
Julabo 9312645

-42-200 ℃ temp. range
0.2-0.4 bar suction rate
0.4-0.7 bar pump pressure
22-26 L/min pump flow

420 W (at -20 ℃)
700 W (at 0 ℃)
80 W (at -40 ℃)
850 W (at 20 ℃)

23 cm × 26 cm × 20 cm

38 cm × 58 cm × 69 cm

26 L

53 kg

For internal and external temperature applications. All HighTech circulators are capable of monitoring an external system directly with an optional Pt 100 temperature sensor. Safety class 3.

• ICC = Intelligent Cascade Control
• Optimum temperature stability with varying systems achieved by the self-tuning controller, adjustable PID control parameters
• VFD Comfort display, resolution to 0.01℃
• RS232 and RS485 interface, option: integrated Profibus
• LCD display (HL model only) for convenient user-guidance, analog/digital setpoint input. Display resolution 0.01 up to 99.99℃
